Figure 24b: Side cross section of the Pillsbury B mill following its 1880s reconstruction. The cross section shows the internal arrangement of a typical roller mill with the drive wheels attached to the turbine in the basement, roller mills on the first floor, flour packers on the second floor, and purifiers and bolting reels on the upper floors.
